Apollo GX50/60/65 Installation Manual
29
APOLLO GX50/60/65 POST-INSTALLATION CHECKOUT LOG
Date: ___/___/___
By: _____________
CONFIGURATION INFORMATION:
GX50 GPS 430-6050-4__ Mod ____ Serial # ___________
GX60 GPS/Comm 430-6050-6__ Mod ____ GPS Antenna ___________
GX65 GPS/Comm 430-6050-8__ Mod ____ Comm Antenna: ___________
TEST MODE CHECKOUT AND SETUP:
Avionics Outputs: Installation Configuration:
[ N/A] CDI (left, mid, right) IFR?: Yes No
[ N/A] VDI (down, mid, up) APPR? Yes No
[ N/A] TO/FROM flag (OFF, TO, FROM) SAR?: Yes No
[ N/A] External annunciators
Serial Interface Configuration:
[ N/A] Valid flags _____________/____________ (Port 1)
_____________/____________ (Port 2)
GPS NAVIGATION CHECKOUT:
Seed position entered
Interface Checks:
Time, date entered [ N/A] RS-232 outputs checked
GPS Operation:
[ N/A] RS-232 inputs checked
Position check
Signal reception check
Interference from other avionics checked
VHF comm interference check
VHF COMM CHECKOUT: (GX60/65 ONLY)
Receiver / Transmitter operation Sidetone level set / checked
Antenna check Flight test operation
[ N/A] Remote flip/flop input
FINAL SYSTEM CHECK:
Database checked Navigation data checked
Direct To waypoint entered
COMMENTS:
