Environmental Qualifications
Apollo MX20 Installation Manual
65
Example Moving Map Data Output (Extended Data Enabled)
AN 34 1570 34°15.70’ latitude
BW 118 4390 118°43.90’ longitude
C306 306° track angle
D210 210 knots
E02682 268.2nm to waypoint
GR0006 0.6nm right of course
I3059 305.9° desired track
KSFO SFO waypoint ident
L3058 305.8° bearing to waypoint
QE140 14.0° east magnetic variation
T--------- No alarms, data not flagged
<binary data> From Table 7
a—O--F Approach Enabled Off, Active Off, Message On, Parallel Track
Off, Hold Off, and From/To is FROM
cvR001 CDI Valid, Needle Right, Deflection 001°
vC000 VDI Valid, Needle Centered, Deflection is 000°
<binary data> From Table 13
tda Flight Plan Waypoint Type data, direct-to, airport type
Figure 22 - Moving Map Data Output (Extended Data Enabled)
