6.3 FLIGHT PLAN WAYPOINT TYPES (WHEN EXTENDED DATA IS
ENABLED ONLY)
The following data is only transmitted when preceded by flight plan data. There is one character per
flight plan waypoint transmitted.
Table 14 - Flight Plan Waypoint Type
Id Item
Format
Len Description
t nnn… 1-21 n = { a (airport) ||
v (VOR) ||
n (NDB) ||
i (intersection) ||
u (user) ||
p (parallel track) ||
d (direct to) ||
F (FAF) ||
I (IAF) ||
H (MAHP) ||
A (IFAF) ||
P (undefined approach waypoint type) }
Example Moving Map Data Output (Extended Data Disabled)
AN 34 1570 34°15.70’ latitude
BW 118 4390 118°43.90’ longitude
C306 306° track angle
D210 210 knots
E02682 268.2nm to waypoint
GR0006 0.6nm right of course
I3059 305.9° desired track
KSFO SFO waypoint ident
L3058 305.8° bearing to waypoint
QE140 14.0° east magnetic variation
T--------- No alarms, data not flagged
<binary data> From Table 9
Figure 21 - Moving Map Data Output (Extended Data Disabled)
