14.9.2023
Rev. [B1]
Page 10 of 28
4. Optimizer string connection
• Configuration A
• Configuration B
5. Rapid shutdown\ Micro-inverter connection
Apollo PV modules may be connected directly to rapid shutdown devices, and micro-inverters. Please
refer to the device technical design guide for specific connection instructions
