7. CAPACITANCE (4000 counts) (Excludes DIGIT switch)
Capacitance 107N 109N
4nF, 40nF *
± (1.50% + 10d) ± (1.50% + 10d)
400nF, 4µF
± (0.90% + 5d) ± (0.90% + 5d)
40µF, 400µF
± (1.20% + 5d) ± (1.20% + 5d)
4mF,40mF
± (1.50% + 5d) ± (1.50% + 5d)
Note : For best measurements, with △ mode on nF ranges.
* With △ mode.
Range : 4nF, 40nF, 400nF, 4µF, 400µF, 4mF, 40mF
Resolution : 1pF in the 4nF range.
Input Protection : 600V rms.
8. FREQUENCY COUNTER (Excludes DIGIT switch)
Range : 20Hz, 200Hz, 2KHz, 20KHz, 200KHz, 1MHz.
Resolution : 0.01Hz in the 200Hz range.
Accuracy : ±(0.01% + 10), ±(0.01% + 50) for 20Hz Range.
Sensitivity : 0.5Vp-p, for 5Hz ~ 1MHz.
Min.Frequency : 5Hz.
Input Protection : 600V rms.
9. DUTY FACTOR (Excludes DIGIT switch)
Range : 20% ~ 80%
Resolution : 0.1%.
Accuracy : ± 1% (20Hz ~ 10KHz, 5Vp-p), ± 2% for 50% ~ 80%
10. Temperature (Excludes DIGIT switch)
Temperature 107N 109N
-100°C ~ 1200°C
± (0.1% + 3°C) ± (0.1% + 3°C)
-200°C ~ -100°C
± (0.1% + 6°C) ± (0.1% + 6°C)
Note : The readings < 360°C on 1°C resolution range when settled as manual
range, display reads “Er” to change to lower range for best measurements.
Multiply the digit accuracy by 2 for °F .
Range : -200°C ~ 1200°C.
Resolution : 0.1°C for –200°C ~ 400°C, 1°C for 400°C ~ 1200°C
Input protection : 600V rms.
