24
3. PEAK HOLD : +[±(0.7% + 20)] additional error for > 20% of full scale and
pulse width greater than 0.5mS; ±(10) more for 50% of full
scale on 2V range. (2000 / 4000 counts)
4. RESISTANCE :
OHM 107N 109N
200Ω, 2KΩ ± (0.30% + 30) ± (0.30% + 30)
20KΩ, 200KΩ ± (0.30% + 30) ± (0.30% + 30)
2MΩ ± (0.30% + 50) ± (0.30% + 50)
20MΩ ± (5.00% + 50) ± (5.00% + 50)
200MΩ * ± (5.00% + 20) ± (5.00% + 20)
2GΩ * ± (5.00% + 8) ± (5.00% + 8)
LV OHM 107N 109N
2KΩ, 20KΩ, 200KΩ ± (0.60% + 20) ± (0.60% + 30)
2MΩ ± (0.60% + 50) ± (0.60% + 50)
20MΩ * ± (7.00% + 50) ± (7.00% + 50)
200MΩ * ± (7.00% + 20) ± (7.00% + 20)
* excludes DIGIT switch.
Resolution : 0.01Ω in the 200Ω range.
Open Circuit Voltage : 3.3V
Open Circuit Low Voltage : 0.6V
Input Protection : 600V rms.
5. CONTINUITY CHECK (Excludes DIGIT switch)
Continuity Threshold : Approx. 50Ω.
Continuity Indicator : 2KHz Tone Buzzer.
Input Protection : 600V rms.
6. DIODE TEST (Excludes DIGIT switch)
Test Current : 1.1mA (Typical)
Open Circuit Voltage : 3.3V DC (max).
Input Protection : 600V rms.
