dBm (typical) : -15 dBm to +55 dBm (0 dBm = 1mW into 600Ω).
dBv (typical) : -80 dBv to + 50 dBv (0 dBv = 1 Vrms).
Note : (ACV and AC + DCV)
Add additional 20 for reading under 0.5 time of range for 5K ~ 50KHz.
Specifications exclude under 0.4 time of range for 50KHz ~ 100KHz.
Resolution : 1µV in the 20mV range.
Input Impedance : 10MΩ, <100pF.
Overload Protection : 1000V dc, 750V rms.
AC Conversion Type : AC Coupled True RMS responding.
AC + DC Volts : Same as AC(RMS) + 1.00% + 80.
Crest Factor : +1.5% addition error for C.F. 1.4 to 3
+3.0% addition error for C.F. from 3 to 4
2. CURRENT :
DCA 107N 109N
20mA, 200mA
± (0.20% + 40) ± (0.20% + 40)
2A, 10A
± (0.20% + 40) ± (0.20% + 40)
ACA 107N 109N
20mA, 200mA, 2A,10A
40Hz ~ 500Hz
± (0.80% + 50) ± (0.80% + 50)
20mA, 200mA, 2A,10A
500Hz ~ 1KHz
± (1.20% + 80) ± (1.20% + 80)
200mA, 10A
1KHz ~ 3KHz
± (2.00% + 80) ± (2.00% + 80)
Range : 20mA, 200mA, 2A,10A.
Resolution : 1µA in the 20mA range.
Burden Voltage : 800mV max. for mA input, 1V max. for A input.
AC Conversion Type : AC Coupled True RMS responding.
Input Protection : Equipped with High Energy Fuse.
1A, 600V, IR 10KV fuse (Bussmann BBS-1 or equivalent) for
mA input.
15A, 600V, IR 100KV fuse (Bussmann KTK 15 or equivalent)
for A input.
AC + DC Current : Same as AC(RMS) + 1.00% + 80
C.F. : Same as ACV.
