Current
Input Impedance : < 2Ω at mA inputs, < 0.1Ω at A
inputs.
Bandwidth : 45Hz to 10kHz
Minimum Resolution : 10uA
Maximum Measuring Time :
1 minutes at A inputs, 10 minutes at mA inputs.
Rest time is 20 minutes minimum.
Function
Range Accuracy
AC
DC
40.00mA
400.0mA
4.000A [1]
10.00A [1][2]
40.00mA
400.0mA
4.000A
10.00A [2]
Sine Wave:
0.8%+3d for 45Hz to 65Hz [3]
2.0%+5d for 65Hz to 1kHz [3]
2.0%+5d for 1kHz to 10kHz [4]
0.2%+2d
0.2%+3d
[1] The bandwidth is 45Hz to 1kHz
[2] When > 10A, accuracy is unspecified and maximum
measuring time is 30 sec.
[3] Below 400 counts of range, add 3d to accuracy.
[4] Below 400 counts of range, add 10d to accuracy.
AC and DC Additional Specifications
Function
Range Accuracy
HFR
40.00mA
400.0mA
4.000A [1]
10.00A [1][2]
AC accuracy + 1.0%
[1] For square wave, the accuracy is unspecified.
AC accuracy + 1.0%
for 45Hz to 400Hz
3.0%+200d for 45Hz to 1kHz [1]
AC+DC
Peak-Hold
The Cut-Off Frequency of HFR: 800Hz (-3dB point)
Attenuation Characteristic of HFR: Approx. -24dB
AC Conversion Type:
The AC conversion type is ac-coupled, true rms
responding, calibrated to the sine wave input.
For non-sine wave add the following Crest Factor
corrections:
