use and maintenance

Atlantic 500

REMOVING THE

REARVIEW MIRRORS

Carefully read page 56 (MAINTENANCE).

The following information refers to a single

rearview mirror, but is applicable to both.

♦ Place the vehicle on the center stand.

NOTE Group the components of the left

and right mirror separately.

♦ Unscrew the cover (1).

Support the rearview mirror (2) to prevent

it from falling accidentally.

Handle all plastic and painted compo-

nents with care to avoid scraping or

scratching them.

♦ Remove the rearview mirror (2) by sliding

it upwards.

♦ Retrieve the cover (1).

REMOVING THE FRONT HOOD

Carefully read page 56 (MAINTENANCE).

♦ Place the vehicle on the center stand.

♦ Unscrew and remove the two screws (3).

Work very carefully.

Do not damage the tabs and/or slots into

which they are fitted.

Handle all plastic and painted compo-

nents with care to avoid scraping or

scratching them.

♦ Unscrew and remove the two screws (4).

When disassembling, be careful to keep

the clips installed on the tabs from fall-

ing out.

ABS

CAUTION
