APRILIA RSV4 FACTORY Service Station Manual

Checking the springs
NOTE
THE FOLLOWING PROCEDURE IS VALID FOR ALL CLUTCH SPRINGS.
•
Check the springs for damage and, if
necessary, replace the them all togeth-
er.
•
Measure the clutch spring length when
unloaded; if necessary, replace the
springs all together.
Characteristic
Minimum wear limit in the release position of
the individual clutch springs
46.8 mm (1.84 in)
Assembling the clutch
•
Insert the thrust bearing with the collar
facing the gearbox
•
Insert the spacer.
Engine RSV4 Factory
ENG - 268

APRILIA RSV4 FACTORY Specifications

General

Displacement	1099 cc
Power	217 HP
Transmission	6-speed
Power RPM	13, 000 rpm
Torque RPM	10, 500 rpm
Seat Height	845 mm
Torque	125 Nm
Front Suspension	Öhlins NIX, 43 mm fully adjustable fork
Rear Suspension	Öhlins TTX36 shock absorber
Front Brakes	Dual 330 mm discs with Brembo Stylema calipers
Rear Brakes	220 mm disc with Brembo caliper
Fuel Capacity	17.9 liters
Fuel System	Electronic fuel injection
ABS	Yes
Frame	Aluminum dual beam
Engine Type	Aprilia longitudinal 65° V4, 4-stroke, liquid-cooled, double overhead camshafts (DOHC), four valves per cylinder
