APRILIA RSV4 FACTORY Service Station Manual

Removing the catalytic converter
•
Remove the exhaust end.
•
Remove the front exhaust manifold.
•
Remove the pinion crankcase
•
Disconnect the oxygen sensor connec-
tor.
•
Release the oxygen sensor cable har-
ness from the clamps.
•
Disconnect the two exhaust butterfly
valve control cables
•
Unscrew and remove the screw from
the cable grommet for the two exhaust
butterfly valve control cables.
•
Release the springs between the rear
exhaust manifolds and the catalytic
converter
•
Remove the catalytic converter.
Removing the exhaust manifold
2 IN 1 FRONT EXHAUST MANIFOLD
Chassis RSV4 Factory
CHAS - 416

APRILIA RSV4 FACTORY Specifications

General

Displacement	1099 cc
Power	217 HP
Transmission	6-speed
Power RPM	13, 000 rpm
Torque RPM	10, 500 rpm
Seat Height	845 mm
Torque	125 Nm
Front Suspension	Öhlins NIX, 43 mm fully adjustable fork
Rear Suspension	Öhlins TTX36 shock absorber
Front Brakes	Dual 330 mm discs with Brembo Stylema calipers
Rear Brakes	220 mm disc with Brembo caliper
Fuel Capacity	17.9 liters
Fuel System	Electronic fuel injection
ABS	Yes
Frame	Aluminum dual beam
Engine Type	Aprilia longitudinal 65° V4, 4-stroke, liquid-cooled, double overhead camshafts (DOHC), four valves per cylinder
