Aprimatic T22 User Manual

1. DESCRIPTION
Device with Aprimatic microprocessor designed to drive one motor with a maximum power
of 680 Watt. The T22 model incorporates a 433,92 MHz radioreceiver module.
1.1 BLOCK DIAGRAM OF THE DEVICE
DL1DL1
DL1DL1
DL1 Power on led
DL5DL5
DL5DL5
DL5 Additional safety/dead man input led
DL2DL2
DL2DL2
DL2 Start led
DL6DL6
DL6DL6
DL6 Open limit switch led
DL3DL3
DL3DL3
DL3 Stop led
DL7DL7
DL7DL7
DL7 Close limit switch led
DL4DL4
DL4DL4
DL4 Photocell led
K1K1
K1K1
K1 Mains power terminal board
K2K2
K2K2
K2 Signals/commands terminal board
K3K3
K3K3
K3 Connector for decoding badge reader and coded keypad / APRIMATIC radio
receiver connector (ONLY for T2E)
J1J1
J1J1
J1 ADD/ON anti-crush card (AUTOREVERSE CARD) connector
P1P1
P1P1
P1 Pause time trimmer
P2P2
P2P2
P2 Brake intensity trimmer
P3P3
P3P3
P3 Torque adjustment trimmer
SW1SW1
SW1SW1
SW1S1-4 Dip switches
* ONLY FOR T22
DL8DL8
DL8DL8
DL8 Start via radio led
DL9DL9
DL9DL9
DL9 Memory System receiver led
K5K5
K5K5
K5 Aerial terminal board
J4J4
J4J4
J4 Receiver memory module connector
JP1JP1
JP1JP1
JP1;
JP2JP2
JP2JP2
JP2 Radio channels function logic selection
JP3JP3
JP3JP3
JP3;
JP4JP4
JP4JP4
JP4 Activation key row selection
JP5-8JP5-8
JP5-8JP5-8
JP5-8 Channel selection jumper (CA41 connection)
SW2SW2
SW2SW2
SW2Receiver programming key
BZ1BZ1
BZ1BZ1
BZ1Buzzer
1.2 TECHNICAL DATA
Voltage 230 VAC (+6% - 10%)
Frequency 50HZ
Fuse protection F5A motor protection quick-acting fuse
Device stand-by consumption 15W
Device max. consumption 680W
Operating temperature -20°C +70°C
Storing temperature -40°C +85°C
Relative humidity 90% max. 90% (non-condensing)
Sealing IP55 (only for IP55 boxes)
F2 F200mA transformer primary circuit quick-acting fuse
F3 F500mA 24V accessories quick-acting fuse
(with motors and accessories connected and functioning)
F1
Fuse protection
Fuse protection
trimmer adjustment
trimmer
DIP SWITCH position
ON
OFF

Aprimatic T22 Specifications
