1. DESCRIZIONE
Apparecchiatura dotata di microprocessore Aprimatic per l’azionamento di 1 motore fino a
680 Watt di potenza massima.
La versione T22 è dotata di un modulo ricevente 433,92 MHz incorporato.
1.1 SCHEMA A BLOCCHI DELL’APPARECCHIATURA
DL1DL1
DL1DL1
DL1 Led presenza rete
DL5DL5
DL5DL5
DL5
Led sicurezza addizionale ingresso uomo
presente
DL2DL2
DL2DL2
DL2 Led start
DL6DL6
DL6DL6
DL6 Led finecorsa apre
DL3DL3
DL3DL3
DL3 Led stop
DL7DL7
DL7DL7
DL7 Led finecorsa chiude
DL4DL4
DL4DL4
DL4 Fotocellula
K1K1
K1K1
K1 Morsettiera di potenza
K2K2
K2K2
K2 Morsettiera segnali/comandi
K3K3
K3K3
K3 Innesto scheda decodifica lettore badge e combinatore a tastiera, o innesto
ricevitore radio esclusivamente modello APRIMATIC (SOLO con T2E)
J1J1
J1J1
J1 Connettore scheda ADD/ON antischiacciamento (AUTOREVERSE CARD)
P1P1
P1P1
P1 Trimmer tempo pausa
P2P2
P2P2
P2 Trimmer intensità freno
P3P3
P3P3
P3 Trimmer regolazione Coppia
SW1SW1
SW1SW1
SW1 Dip switch S1-4
* SOLO CON T22
DL8DL8
DL8DL8
DL8 Led start via radio
DL9DL9
DL9DL9
DL9 Led ricevente Memory System
K5K5
K5K5
K5 Morsettiera antenna
J4J4
J4J4
J4 Connettore modulo memoria ricevente
JP1JP1
JP1JP1
JP1;
JP2JP2
JP2JP2
JP2 Selezione logica di funzionamento canali radio
JP3JP3
JP3JP3
JP3;
JP4JP4
JP4JP4
JP4 Selezione fila tasti di attivazione
JP5-8JP5-8
JP5-8JP5-8
JP5-8 Jumper selezione canali (collegamento CA41)
SW2SW2
SW2SW2
SW2 Tastino programmazione ricevente
BZ1BZ1
BZ1BZ1
BZ1 Cicalino
1.2 DATI TECNICI
Tensione alimentazione 230 Vac (+6% - 10%)
Frequenza 50HZ
F200mA intervento rapido protezione primario trasformatore
Consumo apparecchiatura a riposo 15W
Consumo apparecchiatura 680W (motori e accessori collegati e funzionanti)
Temperatura funzionamento -20°C +70°C
Temperatura stoccaggio -40°C + 85°C
Umidità relativa 90% max non condensante
Grado protezione IP55 (solo se in contenitore IP55)
Fusibile protezione F1 F5A intervento rapido protezione motore
Fusibile protezione F2
Fusibile protezione F3 F500mA intervento rapido protezione accessori 24V
max
regolazione trimmer
trimmer
posizioni DIP SWITCH
ON OFF
