APsystems YC600 - Warranty Card and Installation Map

Y
C600 Installation/User Manual
13
4.APsystems Microinverter System Installation
Figure 12
①. The layout of the inverters' serial numbers on the warranty card is only suitable for
general arrangement.
②. Warranty card is located in Appendix last page of this manual.
③
. You can use Scanning device or mobile phone to scan the serial numbers on the map
when entering the serial numbers in the ECU (see ECU manual).
④
. Using APsystems' mobile app, ArrayApp, can be used complete the installation
registration on site. The Array App is available for iOS and Android.
1 2
3
4 5 6 7
8
9 10 11 12 13 14 15 1716 18 19 20 2221
APsystems Microinverter&Energy Communication Unit
Warranty Card
The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation.
Each APsystems microinverter has a removable serial number label located on the mounting plate. Peel the label and
affix it to the respective location on the APsystems installation map.
Installation Map Template
To register your APsystems microinverter, please mail this warranty registration card to: emasupport@altenergy-power com.
B A
B A
B A
