MANUAL BASIC
SIMPLY POWERFUL· 33·
11 | INITIAL OPERATION - BASIC
• STEP III
• Connect the two hoses to the appliance. To do so, rst pull out the two protective nubs
on “INLET” and “DRAIN” (press the safety ring and pull out the protective nubs). Then in-
sert the hose from the angle stop valve into the “INLET” connection and the hose coming
from the drain clamp into the “DRAIN” connection.
• Pull the hoses several times to ensure that both hoses are rmly seated in their connec-
tions.
• STEP IV
• Pull out the protective nub on the “OUTLET” (press the safety ring and pull out the protec-
tive nub). Push in the last remaining hose and then connect it to the corresponding tap.
• STEP V
• Before you turn the tap on the cold water connection under the sink back on, make sure
to follow the instructions given in the following.
5 6
7 8
