cut using a rotary type cutter
and lubricated using a silicone
grease, petroleum jelly, or
similar, prior to insertion into
the fitting. 15mm pipework
must be used to connect the
product.
If plastic pipe is used, the tube
insert must not increase the
tube diameter or extend the
cut-o length by more
than 2mm.
THESE FITTINGS ARE NOT
SUITABLE FOR STAINLESS
STEEL TUBE. COMPRESSION
FITTINGS MUST NOT BE USED.
Pipe sizing
CHECK PIPE SIZE
REQUIREMENTS FOR
CONNECTIONS TO OUTLETS
AND ACCESSORIES.
Long pipe runs, on both the
inlet and outlet, will reduce
the flow rate at the shower
head, 22mm pipe work should
be used on inlets and reduced
down to 15mm as close to the
valve as possible to reduce
pressure loss and help maintain
flow rate. If using 15mm pipe,
copper pipe is preferred. To
optimise performance minimise
the number of elbows used. If
long pipe runs are unavoidable
on the outlet, and a diverter is
used, use copper pipe rather
than plastic. If plastic pipe is
used, minimise the number of
elbows as the pipe inserts are
very restrictive.
Flushing
Some modern fluxes can be
very corrosive and, if left in
contact, will attack the working
parts of this unit. All soldering
must be completed and the
pipe work thoroughly flushed
out in accordance with current
local and national Water Supply
Regulations prior to connection
of the product.
Declaration of Conformity
Aqualisa Products Limited
declares that the Aqualisa
SmartValve
TM
and supplied
controller, in conjunction with
pairing remotes and diverter,
complies with the essential
requirements and other relevant
provisions of the Low Voltage
Directive (2014/35/EU), the
EMC Directive (2014/30/
EU) and the RED Directive
(2014/53/EU).
Applicable for some models
