Aquatic GP1 - Getting Started; Connections; Connections Diagram; Installation

• GP1 Gauge Size Waterproof Stereo
• User/Installation Manual
• Wiring Harness (AQ-UNH-2)
• Mounting Bracket
• Two (2) Stainless Steel screws
• Two (2) Stainless Steel nuts
1.1 Contents
1. 12-pin Watertight Harness
The 12-pin harness supplies power and ground connections to the stereo and four (4)
speaker channel output connections from the stereo.
Do not cut or modify the 12-pin harness on the stereo side or warranty will be void.
2. AM/FM Radio Antenna Jack
Allows connection of AM/FM radio antenna. For best AM/FM performance make sure the
antenna is extended to the highest achievable position.
3. Auxiliary Outputs
Allows external amplifiers to be connected to power additional speakers.
4. Auxiliary Inputs
Allows an additional RCA input, from a standalone unit or another stereo source.
5. USB Input
Play USB thumb drives with supported audio media and charge devices when connected.
1.2 Connections (see Wiring Diagram 1.3)
Getting Started GP1 WATERPROOF STEREO
3www.aquaticav.com
