Aquor
®
Wall Hydrant V1+
ASSE 1019C / ASME A112.18.1 / CSA B125.1 APPROVED
15
To connect: Line up the three helical grooves on the
hose connector with the three nibs on the hydrant
faceplate. Simultaneously push and twist the
connector clockwise in a smooth motion. Make sure
to align the grooves fully and push in before twisting.
Water flow will start instantly when the connector is
engaged (see image below).
To disconnect: Push the connector in slightly, then
untwist counter-clockwise (see image below). The
hydrant will self-drain any remaining water left in the
body and vacuum breaker assembly. The water will
drain for the few moments, this is perfectly normal.
Remember to de-pressurize your hose before storage.
It’s best to disconnect the hydrant when not in use.
For the longest lifespan, store your Aquor
®
hose
connectors out of the elements.
OPERATION
Tip: If you leave the Aquor
®
connector attached to
your garden hose, make sure to de-pressurize the
hose after use. Temperature changes can cause
water inside to expand, causing excessive pressure
on the connector’s internal check valve (and your
nozzle or accessories) over time.
For installation or other technical questions, please
call our customer service team at 1-800-458-1749.
To connect
To disconnect
Don't get wet!
Remember to attach
a garden hose here
before engaging the
hose connector.
