Please observe the correct polarity and pin placement when connecng the receivers.

Smooth Flite sends telemetry of baery voltage, current and mAh consumpon downlink to the connected re-

ceivers.

Futaba SBUS2 System.

Smooth Flite supports dual SBUS2 receivers. SBUS2 provides up to 16 channels into the Smooth Flite (depending

on transmier) routed to any of the 16 servo outputs. Connect the two supplied receiver cables to SBUS2 ports.

Please observe the correct polarity and pin placement when connecng the receivers. Telemetry is provided

from port R1. No addional translator accessory is required. Only the rst bound receiver will accept telemetry

in a Futaba system. You MUST connect this receiver to port R1 of the Smooth Flite system to receive telemetry.

Je EX-BUS System.

Smooth Flite supports all Je EX-Bus capable receivers. Je EX provides up to 16 channels (depending on trans-

mier) into the Smooth Flite routed to any of the 16 servo output channels. When using two JETI EX BUS receiv-

ers with Smooth Flite you connect receivers to Smooth Flite ports R1 and R2 and to the EXT port of each receiv-

er. Set the receivers to EX bus mode on the Je Transmier. Please observe the correct polarity and pin place-

ment when connecng the receivers. Telemetry is provided via the EX bus cable on Smooth Flite port R1.

JR/DFA X-BUS System.

Smooth Flite supports all JR/DFA receivers with XBUS-A. XBUS-A protocol supports up to 16 channels into the

Smooth Flite (depending on transmier) routed to any of the 16 servo output channels. Connect the two sup-

plied receiver cables to Smooth Flite ports R1 and R2 and then to the receiver . Please observe the correct polar-

ity and pin placement when connecng the receivers. For Telemetry connect port TEL of the Smooth Flite to

the Baery/Sense port of either receiver.

FRSKY.

Smooth Flite supports S-Port capable receivers. Up to 16 channels are available (depending on transmier) into

the Smooth Flite routed to any of the 16 servo output channels. When using two S-Port receivers with Smooth

Flite you connect receivers to Smooth Flite ports R1 and R2 and to the SBUS. Please observe the correct polarity

and pin placement when connecng the receivers. For Telemetry connect port TEL of the Smooth Flite to the S-

Port of the primary receiver.

Spektrum SRXL2 System.

The current version of Smooth Flite supports the full features of SRXL2 protocol. Smooth Flite will receive 16

channels when using SRXL2 receivers and depending on your radio TX capabilies.Telemetry is sent on all SRXL2

receiver connecons when requested by the receiver. Please use 3 x SPM4651T receivers for full range teleme-

try. The SPM4651T use a new 4 pin connector. You will require adaptor leads SKU BRC857 from AR for the

SPM4651T receivers to connect to SF16.

Spektrum SRXL System.

Connect with the supplied receiver cables one or two SRXL receivers to the SF16 ports marked R1 and R2. Con-

nects to the receiver SRXL port (please not the polarity of the port connecon on the receiver) .

Please Note: Spektrum SRXL does not support downlink telemetry from external devices. Receiver voltage is

however sent from the receiver.

System Specic Receiver Installaon

AR SMOOTH FLITE 16 RRS User Manual
