Input Channel to Servo Output Roung
During this stage, we will install the receiver and servos.
Important: Check the recommended voltage range of your servos, supplying excessive
voltage to your servos may cause damage to the servos.
Before connecng any servos to the Smooth Flite we recommend reading through the
following steps. This will allow you to familiarise yourself with Smooth Flite in order to
use it to its fullest potenal.
During the setup if you have mulple servos on a control surface (Example: 2 servos on
an aileron). We recommend seng up the master servo before mechanically connecng
the slave.
Step 1
Ensure that both baeries are plugged into
the Smooth Flite. You will need to plug in
the Smart Screen as it is used for program-
ming. Ensure your receiver is plugged into
the Smooth Flite and your transmier is on
and bound to your receiver.
For more informaon see page 6.
Step 2
Press the green Total mA text on the Smart
Screen, this will take you to the main menu.
Step 3
You should now see the Main Menu
Screen. Press the MONITOR buon
on the screen. This will take you to
the receiver input channel monitor.
