ARB RD116 User Manual

7 Parts List
42
7.2 Itemized Parts List
(See exploded diagram figure 25.)
AIR LOCKER MODEL No. : RD116
ITEM # QTY DESCRIPTION PART #
01
2
SEAL HOUSING O-RING
160207
02
1
SEAL HOUSING ASSEMBLY
081803
03
2
SHIM KIT
SHK009
*
2
MASTER SHIM
150352
04
1
BONDED SEAL
160703
05
1
CLUTCH GEAR
050804
06
1
SPIDER BLOCK
070201
07
1
LONG CROSS SHAFT
060204
08
1
SIDE GEAR
728H081**
09
2
COUNTERSUNK SCREW
200213
10
3
CROSS SHAFT RETAINING PIN
120601
11
2
TAPERED ROLLER BEARING
160101
12
1
FLANGE CAP ASSEMBLY
027304
13
12
RETURN SPRING
150113
14
1
SPLINED SIDE GEAR
728H081**
15
2
SHORT CROSS SHAFT
060403
16
4
PINION GEAR
728H081**
17
4
PINION THRUST WASHER
151110
18
2
SIDE GEAR THRUST WASHER
151010
19
1
DIFFERENTIAL CASE
013004
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170111
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (FRONT)
180210
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATION & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102116
* Not illustrated in exploded view.
** Available only as complete 6 gear set
Part No. 2102116
Revision 7/10/2013
Copyright © 2013 by ARB Corporation Limited
