Arcam A5 - ARCAM Amplifier Component Overview; Front Panel Controls and Indicators; Rear Panel InputOutput Ports

5 ARCAM A5_A15_A25 OM EN
Front Panel
Rear Panel
A5 & A15
A25
This terminal must not be used as a safety
earth.
Phono Ground
Rotate Volume Control
Push to Mute/Unmute or
wake up
Push and Hold for standby
Rotate Input Carousel
Push to Select
Push and Hold to rename
current input
Power Input
CONTROL INPUT
For use with ARCAM Radia
series source components
only
Digital Audio
Inputs
Analog
Audio Inputs
Phono
(MM)
Input
Pre-amp
Outputs
Speaker
Outputs
