AVR200
18
AMPLIFIER SPECIFICATION
Output power (20Hz–20kHz at 0.5%THD)
8Ω, fi ve channels 70W
8Ω, two channels 90W
8Ω, single channel 100W
Harmonic distortion, 1W, 8Ω at 1kHz 0.02% typical
Left/right crosstalk 60dB at 1kHz
Frequency response ±1.0dB 20Hz to 20kHz
Inputs
Line inputs
sensitivity 200mV
input impedance >10kΩ
overload margin >20dB
Power amplifi er input sensitivity 740mV (normal gain)
Outputs
Preamplifi er
nominal output level 200mV
maximum output level 3V
Headphones
output impedance 390Ω
Physical
Dimensions W x D x H 430 x 450 x 150mm
Weight net 11.9kg
Weight packed 14.1kg
Mains voltage 230V ±12%
120V ±12%
Power consumption (maximum) 500VA
Accessories supplied Mains lead
CR-340 remote control
2 x AAA batteries
AM loop aerial
FM ribbon aerial
Technical specifi cations
RADIO SPECIFICATION
FM section
30 preset stations available
RDS Station Identifi cation, Radio Data Display
FM tuning range 87.5 to 108MHz
FM sensitivity < 6µV
THD
mono < 0.25%
stereo < 0.35%
Signal/noise ratio
mono > 72dB
stereo > 66dB
Pilot tone suppression > 60dB
Alternate channel selectivity IHF > 60dB
Capture ratio < 3dB
AM section
10 preset stations available
AM tuning range
10kHz step 530 to 1710kHz
9kHz step 531 to 1602kHz
Usable sensitivity < 30µV
IF rejection > 36dB
Signal/noise ratio, 5mV input > 38dB
THD, 5mV input < 3%
E&OE
Continual improvement policy
Arcam has a policy of continual improvement for its products.
This means that designs and specifi cations are subject to
change without notice.
NOTE: All specifi cation values are typical unless otherwise
stated.
