Arcam AVR400 Service Manual

1
4
2
3
5
SOLDERED TO
POWER AMP PCB
ITEM NO. PART No. DESCRIPTION QTY
1 TGP3534 CHASSIS ASSY 1
2
TGP3535 FRONT PCB ASSY 1
3
TGP3538 POWER AMP PCB ASSY 1
4
TGP3525 FOOT ASSY 4
5
TGP3540 TRANSFORMER - STANDBY 1
80
5
5
TOLERANCES UNLESS 0.00 ± 0.10
OTHERWISE STATED 0.0 ± 0.20
ANGULAR TOL. +2 DEGREES
0 70 90
ALL DIMENSIONS IN
MILLIMETERS UNLESS
OTHERWISE STATED
20
E
F
6
DATE:
DRAWN BY:
1 3
F
A3
A
4
CHECKED BY:
4
MATERIAL:
B
C
DRAWING TITLE
10
A
30
ORIGINAL SCALE 1:4
FINISH:
8
50
2
2
8 7
6
D
SHT 3 OF 4
7
A & R CAMBRIDGE LTD
PART NUMBER AND DRAWING NUMBER
D
23425
60
E
100
1 3
B
C
40
DATE
CHG.
ZONE DESCRIPTION OF CHANGE
REL. DR.
CHK.
--
--
--
--
--
ECO NR.
--
--
--
--
-- --
--
--
--
-- --
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
MCM
7-9-2010
MGB
AVR400 MAIN ASSEMBLY
POWER PCBs + FEET
--
--
--
--

Arcam AVR400 Specifications

General

Output level	6000 mV
Receiver type	-
Frequency range	20 - 20000 Hz
Output impedance	50 Ω
Input sensitivity	4000 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.02 %
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	5
Composite video in	4
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Headphone connectivity	3.5 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Supported radio bands	AM, DAB, FM
HDMI version	1.4a
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic IIx, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Volume control	Rotary
Power consumption (standby)	0.5 W
Power consumption (typical)	100 W
Certification	FCC, CE
Package weight	20000 g
Cables included	AC

Weight and Dimensions

Depth	425 mm
Width	435 mm
Height	172 mm
Weight	15500 g
