Arcam AVR850 Custom Installation Notes

9
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x1D
Dl 0x01
Data 0xF0
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x1D
Ac Answer code
Dl 0x01
Data The current source in the indicated zone:
0x00 – Follow Zone 1
0x01 – CD
0x02 – BD
0x03 – AV
0x04 – SAT
0x05 – PVR
0x06 – VCR
0x08 – AUX
0x09 – DISPLAY
0x0B – TUNER (FM)
0x0C – TUNER (DAB) (AVR450/750 only)
0x0E – NET
0x0F – USB
0x10 - STB
0x11 - GAME
Et 0x0D
Headphone Over-ride (0x1F)
Activate/deactivate the mute relays (does not zero the volume).
Example
Command/response sequence to activate the mute relays:
Command: 0x21 0x01 0x1F 0x01 0x01 0x0D
Response: 0x21 0x01 0x1F 0x00 0x01 0x01 0x0D
COMMAND:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x1F
Dl 0x01
Data 0x00 – Headphone/Over-ride Clear (speakers muted if headphones present)
0x01 – Headphone/Over-ride Set (speakers unmuted if headphones present)
Et 0x0D
RESPONSE:
Byte: Description:
St 0x21
Zn Zone number
Cc 0x1F
Ac Answer code
Dl 0x01
Data1 Relay state
Et 0x0D
Request current source (0x1D)
Request the source currently selected for a given zone.
Example
Command/response sequence to request the current source for Zone 1 where
the source is set to ‘SAT’:
Command: 0x21 0x01 0x1D 0x01 0xF0 0x0D
Response: 0x21 0x01 0x1D 0x00 0x01 0x04 0x0D

Arcam AVR850 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Card reader integrated	No
Package weight	20000 g
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
12V trigger	Yes
12V trigger ports quantity	2
Speakers connectivity type	-
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	16700 g
