SURROUND SOUND RECEIVER

- 2 -

POWER AMPLIFIER AND PREAMPLIFIER SECTION

Rated distortion (THD 20Hz-20 kHz FL/C/FR) ≤ 0.08%

(THD 20Hz-20 kHz SL/SR) ≤ 0.3%

Input Sensitivity (ref. 8 ohms, 1 kHz) 180+/-30 mV

S/N Ratio (A-wtd, 1KHz, 1W, 8 ohm) ≥ -75 dB

(A-wtd, 1KHz, 80W, 8 ohm) FL/FR/C ≥ 92 dB

SL/SR ≥ -90 dB

Frequency Response (20 Hz - 20 kHz) 0 ± 0.8 dB

Channel Balance (1 dB to -40 dB, 1 kHz) ≤ 2 dB

(-41 dB to -50 dB, 1 kHz) ≤ 3 dB

Audio muting at 1kHz ≥ 53 dB

Headphone O/P in 0.1%, 600 ohm load, CD in 500mV, 1 kHz ≥ 10V

Subwoofer out, 500mV in (THD at 2V O/P, 100 Hz) ≥ 0.5%

(S/N at 2V O/P, 100 Hz) ≥ 80 dB

Crosstalk (2V input, 10W, 1 kHz) > -68 dB

Continuous average power output (L/R/C RL/RR 8ohms) 80 W

Controls

Bass (at 500mV in, 1W out, 100 Hz) ±9 dB

Treble (at 500mV in, 1W out, 10 kHz) ±9 dB

SURROUND SECTION

Channel separation

I/p mode : L, R : 1V in, 1 kHz, Ch R, L ≥ 45 dB

: o/p at unexpected, 1 kHz, Ch C ≥ 35 dB

I/p mode : L= -R : 1V in, 1 kHz, Ch R, L ≥ 28 dB

: o/p at unexpected, 1 kHz, Ch C ≥ 30 dB

I/p mode : L= R : 1V in, 1 kHz, Ch R, L ≥ 45 dB

: o/p at unexpected, 1 kHz, Ch SL, SR ≥ 30 dB

Frequency Response

I/p mode : L, R : 1V in, 1W, Ch R, L 40Hz 0 ± 1.5 dB

20kHz 0 ± 0.8 dB

I/p mode : L= R : 1V in, 1W, Ch C 300Hz 0 ± 0.8 dB

20kHz 0 ± 0.8 dB

I/p mode : L= -R : 1V in, 1W, Ch SL, SR 30Hz 0 ± 1.0 dB

6.5kHz -3 ± 1.0 dB

S/N Ratio ( 200mV in, 1, A-WTD w/ 1k termination)

I/p mode : L, R : 1 kHz, Ch L, R ≥ 65 dB

I/p mode : L=R : 1 kHz, Ch C ≥ 65 dB

I/p mode : L=-R : 1 kHz, Ch SL, SR ≥ 65 dB

THD (2.2V in, 1W, w/ 80 kHz LPF, 1 kHz) ≤ 0.2%

AC-3/DTS SECTION

Frequency Response

FL, FR, C, SL, SR: 200Hz 0 ± 0.8 dB

20kHz 0 ± 0.8 dB

Distortion 1W all channels 0.08%

S/N 1 W ( CCIR/ARM, 200 Hz NOTCH & 400 Hz HPF) ≥ 85 dB

PROLOGIC II

AUDIO

Center Width Control (Use track 2 from PLII Audio Test CD ver1.0)

SPECIFICATION

Step L/R C

0 ≤-31dB 0.0dB

1 -12dB -0.6dB

2 -9.6dB -1.1dB

3 -7.6dB -1.8dB

4 -4.8dB -4.6dB

Step L/R C

5 -4.1dB -6.6dB

6 -3.6dB -9.0dB

7 -3.0dB ≤-31dB
