EN-3

Contents

Safety Summary EN-4

Safety Guidelines EN-5

Electrostatic Discharge (ESD) Precautions EN-7

General Information EN-8

PA240 Specications EN-9

Functional Verication and Test Procedure EN-10

Troubleshooting EN-12

Theory of Operation EN-13

Power Amplier PCB - L292 EN-13

Pre-amplier PCB - L288 EN-13

Mains Input PCB - L283 EN-13

Lifter PCB - L308 EN-13

These service instructions are only intended for use by

qualied personnel. Do not perform any servicing other than

that contained in these instructions unless qualied to do so.

Refer to the Safety Guidelines prior to performing any service

L288 Pre Amplier PCB Issue 3 EN-14

L292 Power-Amplier PCB Issue 3 EN-24

L283 PSU PCB Issue 1 EN-40

L308 Lifter PCB Issue 1 EN-44

L285 Front Panel PCB Issue 1 EN-49

Overall Dimensions EN-52

Exploded Drawings EN-54
