Arcam SA30 User Manual

EN-12
ISSUE
DRAWING NO.
DRAWING TITLE
DATE
Filename:
ECO No. DESCRIPTION OF CHANGE
Block diagram.SchDoc
SA30 block diagram
Contact Engineer:
LXXXCT
3/2/2018
INITIALS
Printed:
X YSheet of
Notes:
Contact Tel: +44 (0)1223 203207Peter Kuell
A & R Cambridge Ltd.
Stirling House
Cambridge CB25 9PB
Waterbeach
A3
ARCAM
MM/MC
Line inputsPhono
Analogue Mux
ADC
Flash AKM one
CoaxialOptica l
SPDIF Rx
Flash AKM one
Not Wolfson
I2C
I2C
GPIO
GPIO
SPDIF Mux
GPIO
Avatar
PHY
RealTek
RMII Ethernet
RJ45
USB type A
USB
DAC
ESS9038
I2C
Volume
PGA2311
GPIO
AUX
Analogue
GPIO
Headphone
Amp Phones
Pre out
Power
Amp
direct
Micro U SB
USB
MCU
PICMZ32 one probably
I2C IRQ
Flash
VFD
2 x 16 (same as SA20)
SPI
SPI
SPI Flash
Some Mb
RS232
RS232
MCU control
SPDIF
Analogue
I2S
Avatar control
IR Front panel keys Encoder
Speakers
WiFi

Arcam SA30 Specifications

General

Type	Integrated Amplifier
Input Impedance	10kΩ
DAC	ESS Sabre ESS9038K2M
Network Connectivity	Ethernet, Wi-Fi
Bluetooth	Yes (aptX HD)
Class	Class G
Power Output	120W per channel (8Ω)
Frequency Response	20Hz - 20kHz ± 0.2dB
Total Harmonic Distortion	0.002%
Input Sensitivity	1V
Inputs	1 x Phono MM
Outputs	1 x Headphone
Streaming Services	AirPlay 2, uPnP
Dimensions	433 mm
