arcelik 391641EI - 4.3 Adjustment of the feet

10 /26 EN
Refrigerator / User Guide
Installation
4.3 Adjustment of the feet
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.
In order to adjust the doors vertically,
t-PPTFOUIFGJYJOHOVUBUUIFCPUUPN
t4DSFXBEKVTUJOHOVU$8$$8BDDPSEJOHUPUIF
position of the door
t5JHIUFOUIFGJYJOHOVUGPSUIFGJOBMQPTJUJPO
In order to adjust the doors horizontally,
t Loosen the fixing screw at the bottom
t Loosen the fixing bolt on the top
t Screw the adjusting bolt (CW/CCW) on the side
according to the position of the door
t Tighten the fixing bolt on the top for the final
position
t Tighten the fixing screw at the bottom
Fixing nut
Fixing screw
Sabitleme somunu
Sabitleme vidası
fixing nut
adjusting nut
adjusting bolt
fixing bolt
ayar somunu
ayar civatası
sabitleme
civatası
sabitleme somunu
