ARCHEON EOlife X - Technical Data Relating to the Power Supply

24
EN
2. Technical data relating to the power supply
Specifications Charger
Weight 206 g including accessories
Unit dimensions (L x H x D) 76 x 74 x 44 (± 1mm)
Cable length 1,800mm (± 10mm)
Adapters available
AC input voltage 100 V – 240 V (± 10%)
AC input current Max. 250 mA
AC input frequency 60Hz / 50Hz
DC output current 12V - 1A
Output protection Short circuit
Operating conditions
Storage conditions
0°C to +25°C
-25°C to +70°C
Protection class II
Unit casing materials ABS plastic, in accordance with standard UL 94V-0
USA Europe UK Australia, NZ
Specifications EOlife X battery
Dimensions (W x H x D) 73 mm x 40 mm x 14 mm
Weight 50 g ± 5 g
Shelf life
12 months (with a storage temperature between -10°C and 35°C (-14°F and 95°F)
Charging the device every 6 months allows to increase battery shelf-life .
Type Li-ion
Nominal capacity 1,900 mAh (7.03 Wh)
Nominal voltage 3.7 V
Charging voltage 12V.
Charge time (0% to 95%) Approx. 2 hours
Recommended charging
temperature
+10°C to 45°C
Certifications
IEC 62133
UN38.3
UL1642
