Archgard Optima - Venting Components - Parts List

Optima/ag3600
22
DESCRIPTION PART # DESCRIPTION PART #
Horizontal Termination Kit
In Canada - Mandatory to add a wall thimble.
971
Vertical High Wind Termination Cap
(must be used for all vertical terminations)
991
Vertical Termination Kit 978 Horizontal. DV Termination with 1” return 984GL
6” Pipe Length - Black 908B Horizontal. Square Termination Cap 984
9” Pipe Length - Black 907B Horizontal. Square High Wind Termination Cap 985
12” Pipe Length - Black 906B Snorkel-36” Rise Termination Cap 981
12” Pipe Length - Galvanized 906 Wall Thimble Cover Support Box 940
24” Pipe Length - Black 904B Cathedral Ceiling Support Box 941
24” Pipe Length - Galvanized 904 Brass Trim fro Ceiling Support Box 3951
36” Pipe Length - Black 903B Firestop Spacer 963
36” Pipe Length - Galvanized 903 Flashing 0/12 - 6/12 943
48” Pipe Length - Black 902B Flashing 7/12 - 12/12 943S
48” Pipe Length - Galvanized 902 Storm Collar 953
11” - 14 ⅝” Adjustable Pipe Length - Black 911B Vinyl Siding Standoff 950
17” - 24” Adjustable Pipe Length-Black 917B Wall Strap 988
45° Elbow - Black 945B Wall Pen Heat Shield (Wall Thimble) 942
45° Elbow - Galvanized 945 90° Elbow - Black 990B
45° Elbow - Swivel-Black 945BG 90° Elbow - Swivel-Galvanized 990G
45° Elbow - Swivel-Galvanized 945G 90° Elbow - Swivel-Black 990GB
90° Elbow - Galvanized 990
VENTING COMPONENTS
PART # DESCRIPTION
TVK-1 Archgard Flex Vent Kit with 36” (914 mm) vent length (includes TK-1)
TVK-2 Archgard Flex Vent Kit with 60” (1.52 M) vent length (includes TK-1)
TK-1 Archgard Horizontal termination head only
C-1 Archgard Safety Cage for Horizontal termination head (TK-1)
VSD-1 Archgard Vinyl siding deflector
SDA-U Universal Flex, Simpson Dura-Vent Adapter
DV-GS Simpson Dura-Vent venting system
TVK-10 Archgard Flex Vent Kit with 120” (3.05 M) vent length (includes TK-1)
SNK-24 24” Snorkel
SIMPSON DURA-VENT COMPONENTS
ARCHGARD VENTING COMPONENTS
