Archgard Optima - Replacement Parts List

Optima/ag3600
36
Parts can be ordered through your local dealer or distributor by giving Part # and Description
Part # Description QTY Unit
200-0217 OWNER’S MANUAL, OPTIMA/AG3600 DVT / DVR 1 EA
301-0077 ORIFICE, MALE #54 for PROPANE - DRILL TO #54 1 EA
301-0077 ORIFICE, MALE #43 for NATURAL GAS - DRILL TO #43 1 EA
307-0056 GLASS, CERAMIC (22 ⅜" x 33 ⅛") 1 EA
308-0013
308-0012
SIT Nova 820 NG Valve
SIT Nova 820 LP Valve
1 EA
308-0034
308-0035
SIT HI/LO NG Regulator Assembly
SIT HI/LO LP Regulator Assembly
1 EA
308-0056 THERMOPILE ONLY 750 MV 18” 1 EA
308-0093
PILOT ASSEMBLY, PSE CONVERTIBLE c/w THERMOPILE, THERMOCOUPLE &
ELECTRODE
1 EA
310-0144 LOG LEFT HAND 1 EA
310-0145 LOG RIGHT HAND 1 EA
310-0146 LOG REAR 1 EA
310-0147 LOG FRONT LEFT TWIG 1 EA
310-0148 LOG FRONT RIGHT TWIG 1 EA
311-0077 BRICK PANEL, RIGHT HAND 1 EA
311-0078 BRICK PANEL, LEFT HAND 1 EA
311-0079 BRICK PANEL, REAR 1 EA
CK-LP-3600-SP
CK-NG-3600-SP
CONVERSION KIT-NATURAL GAS TO PROPANE GAS (OPTIONAL KIT)
CONVERSION KIT-PROPANE GAS TO NATURAL GAS (OPTIONAL KIT)
1 EA
305-0021 THERMODISC, 110° FAN SENSOR 1 EA
305-0024 FAN, CROSSFLOW 1 EA
305-0013 FAN, RHEOSTAT 1 EA
314-0009 DOUBLE TADPOLE WINDOW TAPE - 111.5 INCHES 1 EA
300-0137 ORIFICE SPRING 1 EA
LOCA-
TION
A
A
D
E
F
H
J
K
L
B
G
308-0057 THERMOCOUPLE, PSE QDO 1 EA
310-0019 PLATINUM EMBERS, 2 GRAM BAG 1 EA
C
843-0050 BURNER PAN 1 EA
I
843-0104 VALVE TRAY, NATURAL GAS, COMPLETE 1 EA
I
843-0105 VALVE TRAY, PROPANE, COMPLETE 1 EA
REPLACEMENT PARTS
