DVR Station Gen 5
TV ONLY
(
DIAGRAM
C
ON THE CONNECTION GUIDE
)
When connected to your ARCHOS device and TV, the DVR Station will allow you to
do everything described in the Introduction , except scheduling TV recordings.
Connect the DVR Station’s outputs to your TV’s inputs (to display the image of the
ARCHOS device on your TV).
Connect your TV’s outputs to the DVR Station’s inputs (to be able to record from your
television). Verify that your TV has audio/video outputs. Check your television manual.
In order to display the contents of the ARCHOS on your TV, make sure that the
ARCHOS “TV Settings” reect your DVR/TV conguration:
From the Home Screen, select the “Settings” menu item, then choose “Display”.
“TV Standard”: “NTSC (USA)” or “PAL (Europe)”.
“TV Connection”: based on how you have connected the DVR Station.
TV ONLY
(
DIAGRAM
D
ON THE CONNECTION GUIDE
)
If your TV has no audio/video outputs, you will not be able to record from it. You will
only be able to display the contents of the ARCHOS on your TV.
Connect the DVR Station’s outputs to your TV’s inputs.
Make sure that the ARCHOS “TV Settings” reect your DVR/TV conguration:
From the Home Screen, select the “Settings” menu item, then choose “Display”.
“TV Standard”: “NTSC (USA)” or “PAL (Europe)”.
“TV Connection”: based on how you have connected the DVR Station.
FINAL STEPS
Do not place the ARCHOS in the powered DVR Station yet.
If you can still watch TV, it means that you have correctly connected the DVR
Station as a pass-through device.
If you cannot watch TV anymore, this means that there is an incorrect connection.
Check the previous connections steps carefully.
