Archos Gen 5 - Installing the DVR Station

7
USER MANUAL - version 3
Connect the included charger/adapter to the jack labeled dC-in on the back of the
DVR Station.
Then plug the other end of the charger/adapter into an available wall socket.
If you have correctly connected the charger/adapter, the DVR Station’s LED indicator
(on the front of the device, on the right side) will light up.
▲
!
Use only the supplied ARCHOS charger/adapter as other adapters may damage this device (even if they
give the same voltage rating).
2.4. insTalling THe dVr sTaTiOn
The way you install your DVR Station will vary depending on the number of audio-vi-
sual devices you have and how your entertainment system is set up.
These different ways of installing the DVR Station are described in the following sec-
tions.
TUNER AND TV
(
DIAGRAM
B
ON THE CONNECTION GUIDE
)
This shows the basic connection setup of a television source (tuner), the DVR
Station, and your TV.
When connected to your ARCHOS device, TV and tuner (satellite receiver, digital
TV receiver, cable/DSL box, VCR or DVD Recorder), the DVR Station will allow
you to do everything described in the Introduction .
•
•
1
Your tuner needs to be connected to your home antenna/satellite/cable.
2
Connect your tuner’s TV outputs to the DVR Station’s inputs.
3
Connect the DVR Station’s outputs to your TV’s inputs.
4
In order to display the contents of the ARCHOS on your TV, make sure that the ARCHOS
“TV Settings” reect your DVR/TV conguration:
From the Home Screen, select the “Settings” menu item, then choose
“Display”.
“TV Standard”: “NTSC (USA)” or “PAL (Europe)”: select the one that is com-
patible with your country’s television system.
“TV Connection”: based on how you have connected the DVR Station to your
TV.
You can also connect your DVD player (output) either to your TV (if it has secondary input connector)
or to your tuner (if it has an input connector).
