VIPER Detailed hardware description
© 2004 Arcom Issue H 49
JTAG and debug access
Debug access to the PXA255 400MHz XScale processor is via the JTAG connector
PL10 and the reset pin of PL17. The EPI Majic
MX
probe has been used to debug the
PXA255 processor on the VIPER. There are many other debug tools that can be
interfaced to the VIPER for access to the JTAG Interface of the Intel XScale PXA255
processor.
The tables below detail the pins connections between the VIPER and Majic
MX
.
Compare PL10 and PL17 pin numbers to match VIPER JTAG connection to the Majic
MX
connections.
VIPER JTAG Connections
Connector Pin Name Description
1 VCC3 3.3V Supply pin to JTAG debug tool
3 GND Ground reference
3 GND Not required on VIPER.
4 nTRST PXA255 JTAG interface reset
6 TDI JTAG test data input to the PXA255
7 TDO
JTAG test data output from the
PXA255
8 TMS PXA255 JTAG test mode select
PL10
9 TCK PXA255 JTAG test clock
6 RESETSW System reset
- - -
- - Not required on VIPER
PL17
- - Not supported by VIPER
