VIPER Connectors, LEDs and jumpers
Connectors, LEDs and jumpers
The following diagram shows the location of the connectors, LEDs and jumpers on the
VIPER:
PL17
PL6 & LK1 PL4 PL2 PL1
PL16
PL11 & PL12
PL10
PL9 Flash PL7 PL5 PL3
Access
LED
The connectors on the following pages are shown in the same orientation as the
picture above, unless otherwise stated.
© 2004 Arcom Issue H 59
