VIPER Connectors, LEDs and jumpers
Connectors
There are 12 connectors on the VIPER for accessing external devices.
Connector Function Connector Details in Section
PL1 10/100BaseTX Ethernet
interface
PL1 – 10/100BaseTX Ethernet connector
,
page 61
PL2 Ethernet controller status
LED’s
PL2 – Ethernet status LED's connector, page 61
PL3 LCD panel interface PL3 – LCD connector, page 62
PL4 Serial Ports PL4 – COMS ports
, page 63
PL5 CompactFLASH type I/II PL5 – CompactFLASH connector
, page 64
PL6 Audio PL6 – Audio connector
, page 65
PL7 USB PL7 – USB connector
, page 65
PL9 GPIO PL9 – GPIO connector
, page 66
PL10 JTAG PL10 – JTAG connector
, page 66
PL11 64-way PC/104 expansion PL11 & PL12 – PC/104 connectors
, page 67
PL12 40-way PC/104 expansion PL11 & PL12 – PC/104 connectors
, page 67
PL13 Factory use only
(no connector fitted)
-
PL16 Power / battery / external
reset
PL16 – Power connector
, page 68
PL17 &
LK1
Link header PL17 & LK1 – Jumper header
, page 68
