B. Press and hold the Set/Reset But-
ton (4) until the minutes stop
scrolling and the hour display
starts to scroll. Momentarily
release when the correct hour is
displayed; then repeatedly press
and release the Set/Reset Button
(4) until the correct minutes are
displayed.
NOTE: Approximately two seconds
after releasing either Button, the
LCD will return to normal operation.
NOTE: Clock memory power is
supplied through the 15-amp acces-
sory fuse and verified during gauge
“power-up” and reset. In the event of
clock memory power failure (blown
fuse, etc.), the gauge will “power-
up,” reset, and shut down repeatedly
until clock memory power is
restored. Always check the 15-amp
accessory fuse if this gauge condi-
tion is noted.
NOTE: The engine hour meter will
not activate until engine speed
exceeds 500 RPM.
6. Gear Position Indicator - Indicates
which gear is currently selected - R
(reverse)/N (neutral)/L (low range)/H
(high range).
7. Engine Hour Meter Indicator - Indicates
engine hour meter mode is selected on
the display. To select this mode, press
the Mode Button (3) to enter the selec-
tion mode; then press the Mode Button
to until clock/engine hour meter display
is selected. Press the Set/Reset Button
(4) to select the desired function.
8. Needle Indicator Display - Displays
which function (MPH, km/h, or RPM)
is being displayed by the needle.
To select a function, press the Mode
Button (3) to enter the selection
mode; then press the Mode Button to
until the needle indicator display is
selected. Press the Set/Reset Button
(4) to select the desired function.
9. 4WD Lock Indicator - Displays
LOCK when the front differential
lock has been engaged.
10. Drive Select Indicator - Displays 4WD
when selected by the drive select switch
or when the 4WD lock is engaged. The
display is blank when in 2WD.
11. High Beam Indicator - Appears when
the headlights are on high beam.
12. Temperature Indicator - If the engine
coolant temperature exceeds the normal
operating range, the temperature icon
will begin flashing and the LCD will go
blank for 30 seconds; then the LCD will
return to normal. However, the temper-
ature icon will continue to flash.
NOTE: High engine RPM, low vehi-
cle speed, or heavy load can raise
engine temperature. Decreasing
engine RPM, reducing load, and
selecting an appropriate transmis-
sion gear can lower the temperature.
NOTE: Debris in front of the
engine (or packed between the cool-
ing fins of the radiator) can reduce
cooling capacity. Using a garden
hose, wash the radiator and the
engine to remove any debris restrict-
ing air flow.
13. Odometer/Trip Meter Function Dis-
play - Displays which function
(ODO, T1, or T2) is selected.
CAUTION
Continued operation with high
engine temperature may result in
engine damage or premature wear.
CAUTION
Arctic Cat does not recommend
using a pressure washer to clean the
radiator core. The pressure may bend
or flatten the fins causing restricted
air flow, and electrical components
on the radiator could be damaged.
Use only a garden hose with spray
nozzle at normal tap pressure.
