OWNERS MANUAL
5
in.ye dimensions
in.ye overview
Ground input
connection
(European
version shown)
heat.wav heater
with in.flo
technology
Watertight strain
relief system
Access to heater
connections
Mounting feet
Industry-standard AMP
connectors for outputs
Enough outputs for all
your spa needs
Light outputs
(1 direct, 1 switched)
Main keypad connector
Communications link
Accessible
bonding lugs
Front view
Side view
4.98"
(126 mm)
2"
(51 mm)
10.75"
(273 mm)
16.55"
(420 mm)
19.60"
(498 mm)
2.88 "
(73 mm)
10.47"
(266 mm)
1.63"
(41 mm)
2.61"
(66 mm)
Bottom view
4.56"
(115 mm)
2.25"
(57 mm)
4.29"
(108 mm)
7. 16"
(182 mm)
Rear view
17"
(431 mm)
Note: Shown with optional wall mouting brackets (see Installation).
Main power
entry connection
2.38 "
(60.3 mm)
Overview
Outside
Dimensions
Heights
Heater
(Watts)
Water
Capacity
Dry
Weight
Electrical
Requirements
North America
Electrical Requirements
Europe
CHURCHILL
93”x93”
235cm x 235cm
39”
99 cm
NA / Euro
4000 W
463 Gallons
1753 Litres
765 Lbs
347 Kg
240 Volt, 50 Amp
1 phase x 32Amp or 3 phase x
16Amp
LAURENTIAN
93”x93”
235cm x 235cm
39”
99 cm
NA / Euro
4000 W
380 Gallons
1438 Litres
763 Lbs
346 Kg
240 Volt, 50 Amp
1 phase x 32Amp or 3 phase x
16Amp
MALIGNE
86”x86”
218cm x 218cm
41”
104 cm
NA / Euro
4000 W
375 Gallons
1420 Litres
734 Lbs
333 Kg
240 Volt, 50 Amp
1 phase x 32Amp or 3 phase x
16Amp
BAFFIN
86”x86”
218cm x 218cm
41”
104 cm
NA / Euro
4000 W
333 Gallons
1260 Litres
802 Lbs
364 Kg
240 Volt, 50 Amp
1 phase x 32Amp or 3 phase x
16Amp
TIMBERWOLF
75.5”x86”
192cm x 219cm
37”
94 cm
NA / Euro
4000 W
272 Gallons
1030 Litres
630 Lbs
286 Kg
240 Volt, 50 Amp
1 phase x 32Amp or 3 phase x
16Amp
SPA SPECIFICATIONS
BEAR ESSENTIALS CLASS
103
