15
Topside Control Panel
Your spa control has been specically designed so that by simply connecting the spa to a properly
grounded source, and following the start-up procedures in this manual, the spa will automatically heat to the
set temperature. Many other functions, such as ltration, safety checks and maintenance reminders have
been automated so that your spa experience will be as carefree as possible.
But you’re in charge! The topside control (TSC) panel allows you to set the temperature, initiate the
ltration cycle, control the lights, and activate or deactivate the pump(s) and blower. The TSC display
responds to let you know you have pressed a button, and that the selected function has been performed.
Power-Up Detection
When spa is powered up it performs a check to conrm if the hi- limit probe is attached to the heater barrel.
While this is happening “tSt” will be displayed. If the “tSt” fails, the code “HPt” will be displayed on the
screen (Heater Probe Test). Please reference the quick reference guide on the next page for probable
solutions.
Pump 1
Pump 2
Therapy Air
Light Control
Display Panel
Pump 3
Settings
Up
Arrow
Down
Arrow
Function Indicator Section
A small inverted triangle over the symbol indicates that the
corresponding function is active.
Pump 1
Pump 2
Pump 3
Light Control
Display Panel
Pump 4 Pump 5
Up
Arrow
Down
Arrow
Function Indicator Section
A small inverted triangle over
the symbol indicates that the
corresponding function is active.
Owners Manual - Expedition Class
