!! ! Installation!Manual!
Page | 19 support@arecontvision.com
!
!
!
+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com
Manual Zoom / Focus:
+20, +5, +1, -20, -5, -1
Numbers indicate the level of zooming or focusing in order
to adjust the field-of-view.
To set-up a focus area (if necessary), draw a rectangle
with the mouse (by left-clicking and dragging the mouse to
a desired zoom size). To automatically adjust focus,
choose “Full-range Focusing” or “Short-range Focusing”
depending on the image clarity.
NOTE 1: “+20” zooms in 20x further than “+1”
NOTE 2: If the “Enable Auto Focus after Zoom” option is
checked, the focus is automatically adjusted when the
zoom is changed.
Best for scenes that are completely out of focus. The
camera automatically scans the full focus range of the
scene to find the best focus position.
Best for scenes that are slightly of out of focus. The
camera quickly fine-tunes for a precise focus position.
Stops any command in progress.
The higher the focus aid value means the more the lens is
required to focus.
If the focus window box illuminates GREEN, the lens has
reached its optimal focus level (see Image 9).
If the focus window box illuminates RED, the lens is having
difficulty reaching an optimal focus level.
If the focus window box illuminates YELLOW, the focusing of
the lens remains unchanged.
If the focus window box illuminates GREY, the focusing of the
lens has been completed.
NOTE:!Additional!information!regarding!the!Arecont!Vision
®!
web!interface!is!found!separately!in!the!AV IP
Utility Web Browser Manual!via!the!Arecont!Vision!website.!
