Update Documentation P521/EN AD/B21
MiCOM P521 Page 7/24
Input 5
None
Allocation of logic input 5. To allocate a function to logic
input 5, press 5 then use 8 or 2 to select the desired
function from the available list. Validate your choice using
5.
Aux1 Time
tAux1 0 ms
Displays the time delay for auxiliary timer 1 (tAux1). To
adjust the time, press 5. The tAux1 time is adjustable
from 0 ms to 200 s in steps of 10 ms. Validate your
choice using 5.
Aux2 Time
tAux2 0 ms
Displays the time delay for auxiliary timer 2 (tAux2). To
adjust the time, press 5. The tAux1 time is adjustable
from 0 ms to 200 s in steps of 10 ms. Validate your
choice using 5.
3.5.4.10 Broken conductor sub menu
3.5.4.11 Cold load pick-up sub menu
The Cold Load PU allows the user to enable the cold load pick-up function and its
associated settings.
AUTOMAT. CTRL
Heading of the AUTOMAT. CTRL Menu. To gain access to
the Cold Load PU menu, press 2, 6, 6 times, 2,
followed by
6
12 times.
Cold Load PU
Heading of the Cold Load PU sub menu.
To gain access to the sub menu points, press 2.
Cold Load PU?
No
Enables the cold load pick-up function. Select Yes or No.
If the user selects (Yes), the following menu is displayed. If
the user selects (No), the cold load pick-up function is
disabled.
Cold Load PU
tI>? No
Associates the I> time delay threshold with the cold load
pick up function. To associate tI> with the cold load pick
up function, press 5 and select (Yes). Select (No) if the
user does not wish to associate tI> with the cold load pick
up function. Validate your choice using 5.
Cold Load PU
tI>>? No
Associates the I>> time delay threshold with the cold load
pick up function. To associate tI>> with the cold load
pick up function, press 5 and select (Yes). Select (No) if
the user does not wish to associate tI>> with the cold load
pick up function. Validate your choice using 5.
