11.2.2 MiCOM P921-MiCOM P922 and P923 : common information
To gain access to the “AUTOMAT.CTRL” menu from the default display, press 2
once, 6 5 times(P921) or 6 times(P922 and P923), 2 once and 6 once.
LATCH OUTPUTS
Heading of the “LATCH OUTPUTS” menu
LATCH tV<=
NO
Description : selection of the time-delayed information “tV<”,
which will be latched.
Range : YES/NO
LATCH tV<<=
NO
Description : selection of the time-delayed information
“tV<<”, which will be latched.
Range : YES/NO
LATCH tV<<<=
NO
Description : selection of the time-delayed information
“tV<<<”, which will be latched.
Range : YES/NO
LATCH tV>=
NO
Description : selection of the time-delayed information “tV>”,
which will be latched.
Range : YES/NO
LATCH tV>>=
NO
Description : selection of the time-delayed information
“tV>>”, which will be latched.
Range : YES/NO
LATCH tV>>>=
NO
Description : selection of the time-delayed information
“tV>>>”, which will be latched.
Range : YES/NO
LATCH tV0>=
NO
Description : selection of the time-delayed information “tV0>”,
which will be latched.
Range : YES/NO
LATCH tV0>>=
NO
Description : selection of the time-delayed information
“tV0>>”, which will be latched.
Range : YES/NO
LATCH tV0>>>=
NO
Description : selection of the time-delayed information
“tV0>>>”, which will be latched.
Range : YES/NO
LATCH tAUX1 =
NO
Description : selection of the time-delayed information
“tAUX1”, which will be latched.
Range : YES/NO
LATCH tAUX2 =
NO
Description : selection of the time-delayed information
“tAUX2”, which will be latched.
Range : YES/NO
LATCH EQUATION A =
NO
Description : selection of the result of the “A” logic equation,
which will be latched.
Range : YES/NO
