19 SETTING UP THE MACHINE FOR OPERATION
1. Select the proper speed and blade for the type of material you are cutting.
2. Make sure the blade tension is adjusted properly.
3. Raise the saw frame and close the feed ion/off knob (E) Fig. 20.
4. Place the stock (B) Fig. 20, between the vise jaws. Adjust the stock for the desired
length of cut and tighten the vise clamping hand wheel (C).
5. Make sure the blade guide arm (D) Fig. 20, is adjusted as close as possible to the
workpiece.
6. Turn the machine on and adjust the coolant flow.
7. Turn the feed rate control knob (A) Fig. 20, counterclockwise until the saw blade begins
to lower at the desired rate of speed.
8. Proceed to cut through the workpiece. The motor and coolant pump will shut off upon
completion of the cut.
9. After adjusting the down speed (A), the saw frame position and down movement are
controlled by (E) on/off knob.
Fi
