Arfa 1018S - Parts Lists

CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
5S ET1924S
Control Box
1
6S MB240FS
Pump Set
1/8HP 115/230V 1
6-1 181256
Coolant Tank
1
6-2 HD809
Hose
1/2"-350mm 1
6-3 HD659
Coupler
PT1/2x1/4 1
6-4 MB13102
Pump
1/8HP 115/230V 1
6-5 W004
Washer
1/4"x19xt1.5mm 4
6-6 S717
Cross Round Head Screw
1/4"-20*5/8"L 4
7 189036
Pivot Shaft
1
8S 187065BS
Cylinder Assembly
1
9 HCS07
C-Retainer
S18 1
12 189025
Cylinder Upper Bracket
1
13 W205
Spring Washer
5/16"-2.0t 3
14 HS244
Hex. Head Cap Screw
M8-1.25Px30L 3
15 HS064
Hex. Head Screw
M10-1.5Px50L 1
16S 189037S
Length Stop Set
1
16-2 HS422
Hex. Headless Screw
M6-1.0Px10L 1
16-3 189037
Distance Set Rod
1
16-4 198169M
Plum Screw
1
16-5 W004
Spring Washer
1/4"x19xt1.5mm
1
16-6 189038
Support Rod
1
16-7 1966008
Distance Set Bracket
1
16-8 HN006
Hex. Nut
M10-1.5P 1
16-9 HS059
Hex. Head Screw
M10-1.5Px25L 1
17-1S 187055S
Handwheel
1
187055
Handwheel
1
189055R
Knob
1
HS422
Hex. Headless Screw
M6-1.0P6x10L 1
17-3 HK007
Key
5x5x15L 1
24-1 1965043
Model Label
AN05 2
24 HW313
Star Washer
AW05 2
25 CA32005J
Bearing
#32005J 2
26 189013
Gap Ring
1
26-1 189085B
Washer
1
29 196228
Position Set Bracket
1
30 W018
Washer
5/16"x23xt3mm 2
31 HS046
Hex. Head Screw
M8-1.25Px20L 2
32 189012
Rear Pivot Bracket
1
33 191219
Bushing
1
34 HW106
Spring Washer
∮10.2-3t 2
MODEL NO. 1018S
PARTS LIST
-27-
