Arfa 1018S - Page 30

CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
MODEL NO. 1018S
PARTS LIST
35 HS061
Hex. Head Screw
M10-1.5Px35L 2
36 189002G
Base
1
37 HE501
Cross Tablet Head Screw
M5-0.8Px8L 2
38 187064
Degree-Meter
1
39 HS430
Hex. Headless Screw
M8-1.25Px10L 1
40 HN005
Hex. Nut
M8-1.25P 1
41 HS051
Hex. Head Screw
M8-1.25Px45L 1
42 196208
Vise Jaw Bracket
1
43 191209
Bushing
1
44 HW023
Washer
ø10.5*ø21Xt2mm 1
45 HS261
Hex. Head Screw
M10-1.5Px35L 1
46 HW025
Washer
ø10.5*ø27Xt3mm 1
47 181266
Knob
2
48 HS434
Hex. Headless Screw
M8-1.25Px30L 2
49 HW025
Washer
ø10.5*ø27Xt3mm 1
50 191210
Knob
1
51 1966003
Vise Jaw Bracket(Rear)
1
52 HS422
Hex. Headless Screw
M6-1.0Px10L 1
53 1966004
Bushing
1
54 HS261
Hex. Head Screw
M10-1.5Px35L 1
55 N005
Hex. Nut
3/8" 1
56 W014
Washer
3/8"x23xt2 1
57 192040
Spring Handle Bracket
1
58 181118
Spring Adjusting Rod
1
59 187068
Spring
1
60 S022
Hex. Head Screw
5/16"x3/4"L 1
61 W016
Washer
5/16"x23xt2 1
62 N007
Hex. Nut
5/16"-18 1
71 189034
Limit Switch Support
1
71-1 HW004
Washer
ø6.5Xø18Xt1.5mm 2
72 HS334
Hex. Head Screw
M6-1.0PX12L 2
73 ET1617
Switch (For CE Only)
1
74 HW002
Washer
ø4.3Xø9Xt0.8mm 2
74-1 HN002
Hex. Nut
M4-0.7P 2
75 HS513
Cross Round Head Screw
M4-0.7P*30L 2
117 187035
Pivot Shaft
1
121
187001
Coolant Pan
1
200
189023J
Blade Guard (Front)
1
201
196504
Saw Direction Label
1
202
103127
Knob
M6-1.0Px10L 2
