Arfa 1018S - Page 31

CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
MODEL NO. 1018S
PARTS LIST
204
HS243
Hex. Head Screw
M8-1.25Px25L 2
205
HI105
Spring Washer
ø8.2-2.5t 2
206
HW005
Washer
ø8.4*ø17Xt1.6mm 2
207
1965015-1
Blade Adjustable Knob
2
208
HW023
Washer
ø10.5*ø21Xt2mm 2
209-1
189077
Label
2
209
187020
Arm(Left)
2
210
1965014
Gib
2
211 C100
C-Retainer
∮8 4
212 CA6082RS
Bearing
608-2RS 10
213 189018
Eccentric Guide
2
214 189019
Eccentric Guide
2
215
HS230
Hex. Head Screw
M6-1.0Px20L 4
216
103120
Carbide Guide
4
217 121061
Bearing Shaft
2
218 HS421
Hex. Headless Screw
M6-1.0Px5L 4
219 189015
Bearing Bracket (Left)
1
220-1 181980
Valve
2
220-1A 195075
Valve
2
220-2 189088
Hose
∮6 2
220-3 189083 Straight Connector 2
220-4 189084 Press Board 2
220-5 HW104
Spring Washer
∮6.1*1.9 4
220-6 HT016 Bulton Head Screw M6-1.0P*12L 4
221 189014 Blade Adjustable (Rear) 1
222S 189022S
Brush Assembly
1
222-1 189022
Brush Support
1
222-2 191334A
Brush
1
222-3 HW004
Washer
ø6.5Xø18Xt1.5mm 2
222-4 HN004
Hex. Nut
M6-1.0P 2
222-5 HS037
Hex. Head Screw
M6-1.0Px35L 1
223
HS032
Hex. Head Screw
M6-1.0Px10L 1
223-1
HW004
Washer
ø6.5Xø18Xt1.5mm 1
224
HF404
Round Head Screw
M6-1.0PX12L 2
225
189021
Blade Guard ІІ (Rear)
1
226
HN004
Hex. Nut
M6-1.0P 2
227
HW004
Washer
ø6.5Xø18Xt1.5mm 2
230
189091
Micro Switch Bracket(For CE Only)
1
231
HT001
Round Head Screw
M5-0.8Px10L 4
290S
189072S
1
