Arfa 1018S - Specification; Transportation of Machine

2 SPECIFICATION
MOTOR 2HP,,( 1Φ, 3Φ)
60Hz
35-60-88-115 MPM
(114-196-288-377 FPM)
Saw Blade Speed
(for S model)
50Hz
29-50-73-96 MPM
(95-164-239-314 FPM)
60Hz
35~115 MPM
(114~377 FPM)
Saw Blade Speed
(for SV model)
50Hz
29~96 MPM
(95~314 FPM)
Blade Size(mm) 27 x 0.9 x 3090
Dimension L x W x H (mm) 1720x620x1055
N.W / G.W (kgs) 325 / 350
Packing
Measurement 1740 x 762 x 1143 mm
○(mm/inch) 250 / (10 “)
0°
□(mm/inch) 127 x 468 ( 5 “x18 3/8”)
○(mm/inch) 150 (6“)
Cutting
Capacity
+ 45°
□(mm/inch) 175 x 239 (7 “x9 3/8”)
3 TRANSPORTATION OF MACHINE:
Unpacking
1. Transportation to desired location before unpacking, please use lifting jack.(Fig.
B)
2. Transportation after unpacking, please use heavy duty fiber belt to lift up the
machine.
Fig. B
ALLWAYS KEEP PROPER FOOTING & BALANCE WHILE MOVING THIS MACHINE.
- -
6
