CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
MODEL NO. 1018S
PARTS LIST
290
189074
Bracket
1
291
189072
1
292
HS558
Cross Round Head Screw
M5-0.8P*8L 3
293
HW003
Washer
ø5.3*ø10Xt1mm 2
294
HS558
Cross Round Head Screw
M5-0.8P*8L 2
295
189073
Bracket
1
300
HS241
Hex. Head Screw
M8-1.25Px15L 4
301
1965052
Knob
2
302
103127
Knob
M6-1.0Px10L 2
302-1
HW003
Washer
ø5.3*ø10Xt1mm 6
302-2
HT001
Round Head Screw
M5-0.8Px10L 6
303
189027
Blade Back Cover
1
304
HW105
Spring Washer
ø8.2-2.5t 4
305
HN005
Hex. Nut
M8-1.25P 4
306
187026
Cover
1
306-1
189079
Songe Pad
2
307
HS046
Hex. Head Screw
M8-1.25Px20L 1
308
HW027
Washer
ø30Xø16Xt3mm 1
309
CA6205
Tapered Bearing
6025 2
309-1 HCR06 C-Retaniner Ring
R52 2
310
105021A
Idler Wheel
1
311
187056
Shaft
1
312
189033
Handle
1
313
N005
Hex. Nut
3/8" 2
314
187010
Body Frame
1
314-3
HS050
Hex. Head Screw
M8-1.25Px40L 1
314-4 HN005
Hex. Nut
M8-1.25P 2
314-5
189080
Filter
1
314-6
HT001
Round Head Screw
M5-0.8Px10L 1
315
187021
Cover
1
315-1
103127
Hex. Head Screw
M6-1.0Px10L 2
316
187039
Scale
1
316-1
HH001
Rivet
∮2x5L 2
317
HS278
Hex. Head Screw
M12-1.75P*20L 2
318
1965011
Column
1
319
HS432
Hex. Headless Screw
M8-1.25Px20L 4
320
HS089
Hex. Head Screw
M12-1.75P*30L 1
321 HW107
Spring Washer
ø12.2-3.6t 1
322 198036
Drive Shaft Washer
1
323 HK053
Key
8x8x30L 1
-30-
