Arfa 1018S - Page 33

CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
MODEL NO. 1018S
PARTS LIST
324 1965027
Blade
25.4*0.9*3090*5/8Tmm 1
325 196304
Drive Wheel
8MM 1
326
HS258
Hex. Head Screw
M10-1.5Px20L 3
327
HW106
Spring Washer
∮10.2-3t 3
328
19116S-1
Gear Box Assembly
1:30 8mm 1
328
19116S-3
Gear Box Assembly
1:30 8mm 1
330 187069
Shaft
1
330-1 189032
Knob
1
331 HN007N
Hex. Nut
M12-1.75P 1
332 HS266
Hex. Head Screw
M10-1.5Px60L 1
333 105076
Shaft
1
334 105050B
Motor Plate
1
335 105079
Motor Bracket
2
336 HW004
Washer
ø6.5Xø18Xt1.5mm 4
337 HS034
Hex. Head Screw
M6-1.0Px20L 4
338 M601
Motor
1HP(1.1KW)110/220 60HZ 1
339 HK108
Key
8*7*35L 1
340 HW005
Washer
ø8.4*ø17Xt1.6mm 4
341 HS045
Hex. Head Screw
M8-1.25Px15L 4
342 HS032
Hex. Head Screw
M6-1.0Px10L 3
343 HW016
Washer
ø6.5Xø18Xt1.5mm 3
345S 189059JS
Motor Pulley Cover Assembly
1
189058
Pulley Cover
1
189059J
Pulley Cover
1
345-1
103127
Hex. Head Screw
M6-1.0Px10L 1
345-2 HW004
Washer
ø6.5Xø18Xt1.5mm 1
345-3 189086 Bracket 1
348 189029 Spindle Pulley 1
349 HS430
Hex. Headless Screw
M8-1.25Px10L 2
350 189046
Belt
17-330(A32) 1
352 HS430
Hex. Headless Screw
M8-1.25Px10L 2
354S
103127S
3 Way Valve Assembly
1
354-1
103126-4
Hose Clamp
∮12 2
354-2
HD645
Straight Connector
PT1/2" 1
354-3
HD632
Micro Control Block
PT1/2"x3/4" 1
354-4
HD808
Hose Clamp
∮19 2
354-5
103127-4
Net Tube
3/4x80cm 1
354-6
105173
3 Way Valve
1
354-7
HD605
Straight Connector
PT1/2"x1/2"" 1
354-8
HS232
Hex. Head Screw
M6-1.0Px30L 2
-31-
